Engine Type: Single cylinder, 4-stroke, air-cooled

Displacement: 107

Max Torque: 6.18/5500±500 (N.m/r/min)

Bore Stroke: 52.4 x 49.5mm

Ignition: CDI

Starting System: Electric

Battery: 12V, 4Ah

Clutch: Automatic

Transmission: Chain Brakes

Front/Rear: Hub/hydraulic disc

Tires Front/Rear: 145/70-6  145/70-6

Fuel Capacity: 2.4L

Weight: G.W./N.W  176 lbs/154 lbs

Max Load: 60kg

Wheelbase: 800mm

Dimensions: 1230 x 740 x 800mm

Height to Seat: 550mm Min. Ground Clearance: 70mm

This unit is for Pick-up only.

Limited Warranty:

1. Engine:

• Coverage: 6 months from the date of purchase, unless modified or upgraded.
• Warranty: Covers defects in materials and workmanship.
• Conditions: Warranty void if engine system is modified or upgraded.

2. Electrical, Chassis, and Other Components:

• Coverage: 100 miles or 30 days from the date of purchase, whichever comes first.
• Warranty: Covers defects in materials and workmanship.
• Conditions: Applies to electrical components, chassis, and all other parts excluding the engine.
